Matrice 200 Series - Build To Endure. Engineered To Adapt.
BUILT TO ENDURE
High-performance motors paired with 17-inch propellers ensure stable flight in strong winds.
The new dual-battery power system automatically heats batteries when flying in sub-zero temperatures,
while an enclosed design ensures weather and water resistance, so you can fly in a wide range of environments.
INTELLIGENT FLIGHT MODES
ACTIVETRACK
Keep moving subjects in frame while you fly with ease to capture detailed data. Perfect for keeping track of missing persons while you relay their position to a rescue team.
POINT OF INTEREST
Easily circle your object of interest to focus on capturing the data needed for a detailed inspection, compatible with the X4S and X5S cameras.
OBSTACLE AVOIDANCE
A robust FlightAutonomy system with front, bottom and upper sensors detect and avoid obstacles while enabling precision hovering so that you can fly with confidence.
POWERFUL CONTROLS
APP COMPATIBILITY
Conveniently control and customize your M200 Series drone with DJI GO 4 or DJI Pilot, an Android app built for enterprise users. Flight planning can be done using DJI GS Pro.
TRANSMISSION
The M200 series uses DJI’s top of the line Lightbridge transmission system, enabling low-latency controls and live feeds from the aircraft.
DJI AIRSENSE
With a built-in ADS-B receiver, the M200 Series enhances airspace safety by automatically providing the operator with real-time information about nearby manned aircraft.
RELIABLE POWER
Pilots can fly the slim TB50 batteries for improved portability or the larger TB55 batteries to properly support a dual gimbal configuration and increase flight times.
ALWAYS READY
The M200 Series drones fold down in a snap and unfold just as quickly. Gimbal mounting plates and aircraft arms stay mounted during transportation so that you’re ready to fly within minutes.
Aircraft Size and Weight: 716mmx220mmx236mm. 3.80kg
APPLICATIONS
Matrice 200 Series - Specs
AIRCRAFT
| Model | M200 |
| Package Dimensions | 31.1×15.4×11.4inch (790×390×290mm) |
| Dimensions (unfolded) | 34.9×34.6×14.9 inch (887×880×378 mm) |
| Dimensions (folded) | 28.2×8.7×9.3 inch (716×220×236 mm) |
| Folding Method | Folded Inward |
| Diagonal Wheelbase | 25.3 inch (643 mm) |
| Number of Batteries | 2 |
| Weight (TB50) | Approx. 3.80 kg |
| Weight (TB55) | Approx. 4.53 kg |
| Max Takeoff Weight | 6.14KG |
| Max Payload (2 TB50) | Approx.2.34kg (with two standard batteries) |
| Max Payload (2 TB55) | Approx.1.61kg (with two standard batteries) |
| Hovering Accuracy (P-mode with GPS) | Vertical: ±1.64 feet (0.5m) or ±0.33 feet (0.1m, Downward Vision System enabled) Horizontal: ±4.92 feet (1.5m) or ±0.98 feet (0.3m.Downward Vision System enabled) |
| Max Angular Velocity | Pitch: 300° /s；Yaw: 150° /s |
| Max Pitch Angle | P Mode: 30°（Forward Vision System enabled: 25°）； A Mode: 35°；S Mode: 35° |
| Max Ascent Speed | 16.4 ft/s (5 m/s) |
| Max Descent Speed | Vertical: 9.8 ft/s (3 m/s) |
| Max Speed | S Mode: 51.4mph (82.8kph) P Mode: 38mph (61.2kph) A Mode: 51.4mph (82.8kph) |
| Max Service Ceiling Above Sea Level | 1.86 mi (3000 m) |
| Max Wind Resistance | 1.86 mi (3000 m) |
| Max Flight Time(No Payload, with TB50) | 27min |
| Max Flight Time(No Payload, with TB55) | 38min |
| Max Flight Time(Full Payload, with TB50) | 13min |
| Max Flight Time(Full Payload, with TB55) | 24min |
| Motor Model | DJI 3515 |
| Propeller Model | 1760S |
| Operating Temperature | -4° to 113° F (-20° to 45° C) |
| IP Rating | IP43 |
GIMBAL INSTALLATION
| Downward Gimbal Mount | Supported |
| Upward Gimbal Mount | Not Supported |
| Downward Dual Gimbal | Not Supported |
BATTERY (STANDARD)
| Model | TB50 |
| Capacity | 4280 mAh |
| Voltage | 22.8V |
| Battery Type | LiPo 6S |
| Energy | 97.58 Wh |
| Net Weight | Approx. 520g |
| Operating Temperature | -4° to 113° F (-20° to 45° C) |
| Storage Temperature | Less than 3 months: -4° to 113° F (-20° to 45° C) More than 3 months: 72° to 82° F (22° to 28° C) |
| Charging Temperature | 41° to 104° F (5° to 40° C) |
| Max Charging Power | 180 W |
CHARGER
| Model | IN2C180 |
| Voltage | 26.1 V |
| Rated Power | 180 W |
FORWARD VISION SYSTEM
| Obstacle Sensing Range | 2.3-98.4 feet (0.7-30 m) |
| FOV | Horizontal 60°，Vertical 54° |
| Operating Environment | Surfaces with clear patterns and adequate lighting (> 15 lux) |
DOWNWARD VISION SYSTEM
| Velocity Range | <32.8 ft/s (10 m/s) at the height of 6.56 feet (2 m) |
| Altitude Range | <32.8 feet (10 m) |
| Operating Range | <32.8 feet (10 m) |
| Operating Environment | Surfaces with clear patterns and adequate lighting (> 15 lux) |
| Ultrasonic Sensor Operating Range | 0.33-16.4 feet (10-500 cm) |
| Ultrasonic Sensor Operating Environment | Non-absorbing material, rigid surface (thick indoor carpeting will reduce performance) |
GIMBAL
| Compatible Gimbals | Zenmuse X4S Zenmuse X5S Zenmuse Z30 Zenmuse XT |
REMOTE CONTROLLER
| Model | GL6D10A |
| Operating Frequency | 2.400-2.483 GHz 5.725-5.850 GHz |
| Max Transmitting Distance(unobstructed, free of interference) | 2.4 GHz: 4.3 miles (7 km, FCC); 2.2 miles (3.5 km, CE); 2.5 miles (4 km, SRRC) 5.8 GHz: 4.3 miles (7 km, FCC); 1.2 miles (2 km, CE); 3.1 miles (5 km, SRRC) |
| EIRP | 2.4 GHz: 26 dBm (FCC); 17 dBm (CE); 20 dBm (SRRC) 5.8 GHz: 28 dBm (FCC); 14 dBm (CE); 20 dBm (SRRC) |
| Video Output Ports | USB, HDMI |
| Power Supply | Built-in battery |
| Charging | DJI charger |
| Dual User Capability | Host-and-Slave connection |
| Mobile Device Holder | Tablet or Smart Phone |
| Max Mobile Device Width | 170 mm |
| Output Power | 9 W (Without supplying power to smart device) |
| Operating Temperature | -4° to 104° F (-20° to 45° C) |
| Storage Temperature | Less than 3 months: -4° to 113° F (-20° to 45° C) More than 3 months: 72° to 82° F (22° to 28° C) |
| Charging Temperature | 32° to 104° F (0° to 40° C) |
| Battery | 6000mAh 2S LiPo |
| USB Supply Power | iOS: 1 A @ 5.2 V (Max); Android: 1.5 A @ 5.2 V (Max) |
BATTERY (OPTIONAL)
| Model | TB55 |
| Capacity | 7660 mAh |
| Voltage | 22.8V |
| Battery Type | LiPo 6S |
| Energy | 176.93Wh |
| Net Weight | Approx. 885g |
| Operating Temperature | -4° to 113° F (-20° to 45° C) |
| Storage Temperature | Less than 3 months: -20° C to 45° C More than 3 months: 22° C to 28° C |
| Charging Temperature | 41° to 104° F (5° to 40° C) |
| Max Charging Power | 180 W |
DJI GO 4 APP
| Name | DJI GO 4 |
| Mobile Device System Requirements | iOS 9.0 or later,Android 4.4.0 or later |
| Supported Mobile Devices | iOS:iPhone 5s, iPhone SE, iPhone 6, iPhone 6 Plus, iPhone 6s, iPhone 6s Plus, iPhone 7, iPhone 7 Plus, iPad Air, iPad Air Wi-Fi + Cellular, iPad mini 2, iPad mini 2 Wi-Fi + Cellular, iPad Air 2, iPad Air 2 Wi-Fi + Cellular, iPad mini 3, iPad mini 3 Wi-Fi + Cellular, iPad mini 4 and iPad mini 4 Wi-Fi + Cellular. This app is optimized for iPhone 7, iPhone 7 Plus. Android:Samsung tabs 705c, Samsung S6, Samsung S5, Samsung NOTE4, Samsung NOTE3, Google Nexus 6p, Nexus 9, Google Nexus 7 II, Ascend Mate7, Huawei P8 Max, Huawei Mate 8, LG V20, Nubia Z7 mini, Sony Xperia Z3, MI 3, MI PAD, Smartisan T1. *Support for additional devices available as testing and development continues. |
UPWARD INFRARED SENSOR
| Obstacle Sensing Range | 0-16.4 feet (0-5 m) |
| FOV | ±5° |
| Operating Environment | Large-sized object with diffuse relecting surface or high relective rate (>10%） |
